| Part Number (P/N) |
C1FA18031
|
| INTERFACE |
Ethernet 10/100/1000 via RJ45 x1
|
| POWER |
PoE 802.3at Class 4
|
| POWER CONSUMPTION |
12.5W
|
| VIDEO OUTPUT |
- 640x320@30fps
- 1920x960@30fps
- 1920x1080@30fps
- 3840x1920@30fps
- 5760x2880@30fps
- 7680x3840 (8K) @15fps
- H.264/H.265 in RTP/RTSP streaming
|
| CONTROL |
Compatible with ONVIF profile S (T / M planned) / OSC API
|
| OPTICAL FEATURES |
- 360° (Horizontal) x 180° (Vertical) field of view F2.2 aperture
- 1/1.8" 8M CMOS sensor x4
|
| AUDIO |
Microphone x1
|
| PHYSICAL FEATURES |
- 68 × 68 × 204 mm (Not including accessory cap, lens, PoE Cable)
- Approximately 1.33 kg
- ¼” camera screw hole
- PMS 877 C Aluminum / Anodized / IEC60529_IP66
- MIL-STD-810H Environmental Testing:
- Transit Drop (6 ft / 1.83 m)
- Random Vibration
- Functional Shock
- Thermal Shock
- Humidity
- Salt Fog
- High / Low Temperature Operation
- Solar Radiation / UV Resistance
|
| TEMPERATURE |
- Operating Temperature: -10°C to 50°C
- Storage Temperature: -20°C to 60°C
|
| HUMIDITY |
5% to 90% relative humidity, non-condensing
|
| SHOCK RESISTANCE |
- Drop Testing (IEC 60950-1)
- 6 ft (1.83 m) drop test onto concrete floor
- Top and bottom faces only (excluding lens side)
|
| VIBRATION RESISTANCE |
- Vibration (IEC 60068-2-64)
- Random vibration along three perpendicular axes for 2 hours with 0.41G RMS acceleration level over 3 to 500Hz
|
| ELECTRICAL SAFETY |
- CB: IEC 62368-1 : 2018 ED.3
- EU / CE: EN 62368-1 ED.2
- New Zealand / Australia: AS/NZS 62368-1 ED.2 test
- Taiwan / safety: CNS 15598-1
|
| EMI/EMS REGULATION |
- Taiwan / EMC: BSMI(CNS15936)
- EU / CE: EN 55032 / EN 55035, Class A
- USA / FCC: 47 CFR Part15, Subpart B, Class A
- Canada / ISED: ICES-003, Issue 7, Class A
- AS/NZS: CISPR 32, Class A
|
| ENVIRONMENTAL REGULATION |
GP Compliance
|
| COMPLIANCE |
NDAA
|
| Night Vision |
Supported with IR illumination
|
| Patrol Function |
Built-in Cupola360+ Patrol Lite
|
| IoT Protocols Supported |
MQTT, MODBUS, REST API
|
| Edge AI Features |
People counting, virtual fencing, fire & smoke detection, PPE detection (helmet, vest, mask), vehicle flow monitoring, license plate recognition, etc.
|
| Cybersecurity |
- Enterprise-Grade Cybersecurity: HTTPS TLS
- Winbond W77Q
- BIS Security
- Security Boot
|
